Tamiya 47528 1/14 Volvo FH16 Globetrotter 750 8x4 Tow Truck Silver Edition RC Kit
- SKU:
- 47528
- Brand:
- Tamiya
This R/C assembly kit depicting the Volvo FH16 Tow Truck is a special limited-edition release that includes the ABS body pre-painted in TS-17 Gloss Aluminum, with a urethane clear top coating for a high-quality finish.
About the Volvo FH16 Tow Truck
Volvo is a renowned actor in the global commercial vehicle market, with one of their flagship brands being the FH Series that underwent a full model change in 2012. This R/C model assembly kit recreates the 750hp engine FH16 Globetrotter 750 8x4 tow truck from that range. The model has a realistic cab and body, the former featuring a photo-etched front grille and interior details, the latter opening doors. The trucks fascinating towing mechanism uses metal parts and winch boom, under lift and outriggers are movable manually. The front mounted TR Mighty Tuned motor (35T) provides ample power to the two rear axles, via a three-speed transmission. Gear changes are also possible via transmitter controls, and the model can tow subjects such as 1/14 scale R/C tractor trucks.
Optional Extras for Ultra Realism
Item 56553 Electric Actuator Set for 1/14 Scale R/C Tow Truck -This separately sold set allows raising of the winch boom and under lift via R/C controls. It uses a precision geared motor and spindle cylinder, plus the ACU-02 unit, and features a toggle switch for manual control.
Item 56523 Tractor Truck Multi-Function Control Unit MFC-03 - Tamiya Multi-Function Control Units (sold separately) offer light, sound, and vibration operation to go with your R/C truck experience. Engine sounds have been digitally recorded from actual trucks, and together with air horn, gear shifting, and various other realistic sounds, give you the feeling that you are driving the real thing! Headlights, brake lights, fog lamp, hazard lights and turn signal operations are also at your fingertips.
Key Features:
- 1/14 scale R/C model assembly kit. Length: 732mm, width: 199mm, height: 309mm.
- The highly realistic cab, plus H, M, DD, HH, LL, MM, and NN parts are molded in gray and pre-painted in TS-17 Gloss Aluminum, with a urethane top coating.
- This model’s front axles feature twin steering system.
- Includes metal components for excellent durability.
- Install the new separately available Actuator Set (Item 56553) to control its actions via your R/C transmitter.
- Ladder frame has aluminum side channels and resin cross members. Power from the front motor is delivered to the two rear axles via a propeller shaft.
- A built-in differential gear on each axle enables smooth cornering.
- Highly realistic suspension uses metal leaf springs and friction dampers.
- The model enjoys easy driving thanks to the float-mounted die-cast front and reinforced resin rear axles.
- Three-speed transmission allows shifting via the R/C transmitter (Note: only one gear is usable when towing).
- Headlights and taillights can be lit up with separately sold LEDs, and the model is compatible with Item 56523 Tractor Truck Multi-Function Control Unit "Euro-Style" (MFC-03).
- Compatible TROP truck option parts: 56523, 56531, 56538, 56548, 56549, 56550, 56551, 56553.
What's In The Box?
- Tamiya Volvo FH16 Globetrotter 750 8x4 Tow Truck (Silver Edition) Assembly Kit
- Decal Sheet
- Assembly Instructions
Required for Operation (Not Included)
- 4-Channel R/C System with slide trim levers and self-neutral sticks
- Servos x2
- ESC or Multi-Function Control (MFC) Unit (MFC-03 recommended)
- R6/AA/UM3 batteries for transmitter
The massive, stately form of this tow truck is captured with exceptional realism. Body parts are painted in silver with a urethane topcoat.
Stainless steel photo-etched front grille parts add to the authenticity. Separately sold LEDs can be used to light the model up.
Visor and roof lights are metal plated components for that extra touch. Escape hatch, antenna and so on are recreated in style.
Both front axles are steered on this model, with a single servo used to turn the wheels. Wheels turn realistically at different angles.
A look here at the base ladder frame chassis, which is a sturdy affair composed of aluminum side channels and plastic cross members.
The body of the truck is adorned with a light bar that is constructed using a clear orange case and can be lit up with separately sold LEDs.
Boom length and angle can be adjusted, the former up to an impressive 586mm long. Three different angles are selectable.
The underlift can be extended and retracted, and features adjustable forks. It turns on a joint to enable smooth cornering.
Opening doors on the body give a realistic look, and also allow access to install separately sold MFC and Actuator units.
Outriggers are affixed via cap screws, which can be loosened to allow manual extension, and give a further layer of realism.
This is a close-up on the rear suspension, where a trunnion setup is employed using metal leaf springs and friction dampers.
Technical Specifications:
Adjustable Gear Ratio: 3-Speed Transmission
Bearings: Plastic bushing & Metal Bearings
Body Material: ABS Plastic
Body Stickers: Included
Chassis Material: ABS Plastic & Aluminum
Chassis Type: Semi-Truck
Construction Type: Assembly Kit
Differential Type: Gear
Drive Type: 2WD
Electronic Speed Control (esc): Sold Separately
Led Lights: Sold Separately
Motor: 540-brushed type
Scale: 1/14
Shock Damper: Friction damper
Suspension: Leaf Spring
Terrain Use: On-Road
